Data sheet:
Years built: | 1974 -1978 |
Bikes produced: | Overall total: 12112 |
Price in 1974: | |
Vehicle Ident. # (VIN): | 5D |
Model designation letter: | SX |
Frame: | Double downtube, two different versions (74-75 and 76-78) |
Top Speed: | 71.5 MPH (115 km/h) |
Spark Plug: | Champion no. 2 |
Electrical System: | 12 Volt, breakerless ignition |
Engine
Type: | 2-Cycle, Vertical Single Aluminium Cylinder, 175 Cubic Centimeters, Chrome Bore |
Bore: | 2.40 Inches (61 mm) |
Stroke: | 2.34 Inches (59,6 mm) |
Piston displacement: | 174.1 cc |
Carburetor: | Dell'Orto, VHB 27AD, concentric |
Compression ratio: | 10.7:1 |
Lubrication system: | oil pump, integral oil reservoir located in tubular frame with 1.76 quarts capacity |
Starter system: | kick start, right side |
Overall length: | 84.5 Inches (74-75); 85.8 Inches (76-78) |
Handlebar width: | |
Ground clearance: | 9 Inches (74-75) 6.7 Inches (76-78) |
Wheelbase: | 54 Inches (74-75) 55.7 Inches (76-78) |
Seats: | One seater in 1974 and 1975; 1976 and later two seater |
Saddle Height: | 32 Inches (74-75); 37.1 Inches (76-78) |
Front suspension: | Hydraulic 32mm by Marzocchi, Ceriani or Betor (different by year and country sold) |
Rear suspension: | Twin Shocks, 5 way adjustable (74-75) |
Fuel tank: | 2.77 Gallons (10.5 liters) |
Transmission System:
Clutch: | wet, multiple plates |
Gear ratios: | 1st: 2.53, 2nd: 1.79, 3rd: 1.305, 4th 1.0, 5th: 0.8 |
Gearshift pattern: | 5-Speed, left side shift; 1st down - 4 up |
Wheels and Brakes
Front wheel tire: | 3.00 x 19, knobby type |
Rear wheel tire: | 3.50 x 18, knobby type |
Front brake: | Drum brake 140 mm, single lead shoe |
Rear brake: | Drum brake 140 mm, single lead shoe |
Rims (Front & Rear): | 19" front and 18" rear |
Tire pressure (Front): | |
Tire pressure (Rear): |
The
SX-175 was introduced in 1973 as a 1974 model year. At the same time
the factory in Varese stopped producing the single cylinder 4-stroke
bikes and from now on you could only get 2-stroke single cylinder bikes
from AMF Harley-Davidson. For it's time the bike
was equipped with some modern features: Whats the difference between a SX-175 and a SX-250?
|
