AMF Harley-Davidson Z-90

Years built:	1973, 1974, 1975
Bikes produced:	8244 bikes for 1973, 7168 bikes for 1974 and 2562 bikes for 1975
*Price in:*
*Vehicle Ident. # (VIN):*	3D
*Engine:*	2-Cycle, Single Cylinder, 90 Cubic Centimeters, Air Cooled
*Bore and Stroke:*	1.89 x 1.95 Inches
*Spark Plug(s):*	HD 5R6A, Harley Davidson No. 5-6 (owners manual),
*Compression Ratio:*	9.22:1
*Ignition Timing:*
Breaker Point Gap:
Gas Capacity:	2.4 Gallons
Transmission:	4-Speed
Carburetor:	Dell'Orto ???
Electrical System:	12-Volt
Saddle Height:	29.7 Inches
Ground Clearance:	6.5 Inches
Wheelbase:	46.5 Inches
*Length (overall):*
*Width (overall):*
Weight:
*Wheel Rim:*
Tire Size (Front):	2.50 x 17
*Tire Size (Rear):*	3.25 x 16

The Z-90 engine is the same as on the X-90.

The 90cc Z-90 is in some way uncommon. It is larger than other minibikes like a Honda Monkey or a Harley-Davidson X90, but still much smaller in overall size like a 125cc motorcycle.
An adult riding that vehicle looks outgrown to the bikes dimensions. So, one must assume the target group for that bike was teenagers who are starting to ride a bike.
In the move "The Bad News Bears" with Walter Matthaus from 1976 this bike is ridden by one of the main (teenager) actors. If you have a passion for two stroke Aermacchis you have to watch that movie at least once. :-)

Picture No. 1 and No. 2 shows a 1974 Z-90
Picture No. 3 shows the owners manual that was delivered with the new bike
Picture No. 4 shows the Z-90 parts catalog

Photo: Sven Döhler
